The UUID (Universally Unique Identifier) system, though traditionally applied across various sectors, has shown to be suboptimal, particularly in environments requiring lexicographical order sorting, compact data representation, and guaranteed uniqueness within a limited time window. To address these challenges, a new identifier system - ULID (Universally Unique Lexicographically Sortable Identifier) - is proposed.
Components of ULID
Timestamp: This component utilizes 48 bits to encode the millisecond-precision timestamp, offering a time range of approximately 10888 years. Starting from Unix epoch time (1970), it extends forward, making it highly suitable for time-sensitive applications.
Randomness: To ensure uniqueness and mitigate collision risks within the same millisecond, 80 bits of cryptographically secure random data are added. This significantly increases the identifier’s robustness.
Sorting Requirements
ULID's sorting mechanism leverages lexicographical order, meaning that when viewed as a string, identifiers can be sorted accurately from start to finish. This is done using the default ASCII character set. It’s essential for applications where records need to be indexed in a database or logs need sequential sorting based on creation time.
Canonical String Representation
Crockford’s Base32 is used for the ULID string representation, chosen specifically to exclude ambiguous characters like 'I', 'L', 'O', and 'U', reducing the risk of misinterpretation and abuse. This representation ensures case insensitivity and readability, essential in environments where identifiers are often manually inspected or entered.
Image: Crockford's Base32 alphabet ensuring readability
Monotonicity in Same Millisecond
Monotonicity is critical for applications stressing order within the stringent bounds of a millisecond. ULID addresses this by incrementing the least significant bit of the random component, ensuring order preservation. This extends to generating up to 280 ULIDs within the same millisecond before experiencing potential overflow.
Binary Layout and Byte Order
In binary form, ULIDs are composed of 16 octets, with network byte order (Most Significant Byte first). This facilitates straightforward binary comparisons and interoperability across different systems and platforms.
Implementation and Community Adoption
Though primarily implemented in JavaScript, ULID specifications are available in several programming languages, driven by both the primary developers and the wider open-source community. This cross-language availability ensures ULID’s applicability in diverse technological environments, from back-end servers to IoT devices.
---
Remember these 3 key ideas for your startup:
Enhanced Sorting and Uniqueness: Unlike UUIDs, ULIDs allow for efficient lexicographical sorting, making them ideal for databases and logging systems. This ensures traceable, human-readable entries, crucial for debugging and analytics.
Readability and Usability: The use of Crockford’s Base32 alphabet makes ULIDs easier to read and transcribe while avoiding common ambiguities. This reduces human errors, particularly in manual data entry scenarios or quick inspections.
Guaranteed Monotonicity: In use-cases where multiple identifiers are generated within the same millisecond, ULIDs provide guaranteed, sequential ordering by incrementing the randomness byte. This is invaluable in high-concurrency environments such as fintech applications, event streaming, and logging systems.
